The generator set has a compact structure and a small footprint, making it easy to install and maintain.
The engine is designed with advanced technology and has a reliable performance, providing a stable power supply for the ship.
The generator uses a digital automatic control system to monitor and control the operation of the engine and generator, ensuring safe and stable operation.
The generator set has low fuel consumption and meets the emission standards set by the International Maritime Organization (IMO).
The generator set has a wide range of applications, and can be used as the main power supply or backup power supply for various types of ships.
The generator set has a low noise level and vibration, providing a comfortable environment for the crew and passengers.
The generator set has a long service life and requires minimal maintenance, reducing the overall operating costs for the ship.
The generator set is manufactured with high-quality materials and components, ensuring a high level of reliability and durability.
Diesel Generator | Genset Model | 40GFJ |
Rated Frequency | 50HZ | |
Power Factor | 0.8 | |
Rated Voltage | 400/230V | |
Rated Power(KW/KVA) | 40/50 | |
Standby Power(KW/KVA) | 44/55 | |
Phase/Wire | 3/4 | |
Diesel Engine | Origin | Weifang,China |
Engine Model | ZH4100ZCD | |
Rated Power(kw/r/min) | 45/1500 | |
Intake Type | Turbocharger | |
No. of Cylinder | 4 | |
Bore×Stroke(mm) | 100×115 | |
Compression Ratio | 17:1 | |
Exhaust Temperature(℃) | ≤540 | |
100%output Fuel Consumption(L/h) | ≤251.6 | |
Displacement(L) | 3.61 | |
Alernator | Rated Power(KW/KVA) | 40/50 |
Voltage Regulation | ≤±5 | |
Excitation Type | Brushless | |
Metrial | 100% Copper | |
Rated Frequency | 50HZ | |
Insulation Class | H |
