Reliable power supply: The generator set can provide a stable and continuous power supply for the ship's electrical system, ensuring reliable operation of all onboard equipment.
Efficient operation: The generator set is designed to operate with high efficiency, reducing fuel consumption and operating costs.
Compact size: The 64KW marine generator set is designed to be compact and space-saving, which is especially important for ships where space is limited.
Easy maintenance: The generator set is designed to be easy to maintain and service, reducing downtime and maintenance costs.
High quality components: The generator set is built with high-quality components that are designed to withstand the harsh marine environment, ensuring long-term reliability and durability.
Low emissions: The generator set is designed to comply with strict marine emissions regulations, reducing the ship's environmental impact.
Customizable options: The 64KW marine generator set can be customized to meet the specific requirements of different ship types and applications.
Diesel Generator | Genset Model | 64GFJ |
Rated Frequency | 50HZ | |
Power Factor | 0.8 | |
Rated Voltage | 400/230V | |
Rated Power(KW/KVA) | 64/80 | |
Standby Power(KW/KVA) | 70.4/88 | |
Phase/Wire | 3/4 | |
Diesel Engine | Engine Brand | Weifang,China |
Engine Model | R6105ZCD | |
Speed regulation mode | Mechanical speed regulation | |
Rated Power(kw/r/min) | 84/1500 | |
Intake Type | Turbo charger | |
No. of Cylinder | 6 | |
Bore×Stroke(mm) | 105×125 | |
Compression Ratio | 16:1 | |
Exhaust Temperature(℃) | ≤600 | |
100%output Fuel Consumption(L/h) | ≤231 | |
Displacement(L) | 6.49 | |
Alernator | Rated Power(KW/KVA) | 64/80 |
Voltage Regulation | ≤±5 | |
Excitation Type | brushless | |
Material | 100% Copper | |
Rated Frequency | 50HZ | |
Insulation Class | H |
